C9Z490-PG
Motherboard Supermicro MBD-C9Z490-PG Z490 Express LGA1200 Intel Core 10th i9 i7 i5 i3 LGA1200 SATA M.2 DDR4 IPMI
Net: $ 425.86
Gross: $ 523.81
Manufacturer: Supermicro
Part number: C9Z490-PG
Warehouse product ID: 658519
HS: 8473 30 20 00
ECCN: 5A992C
Availability*: On order (estimated delivery time from 10 to 21 business days)
* Please remember that delivery times are also influenced by events beyond our and the manufacturer's control, such as random events, armed conflicts or natural disasters.
Delivery cost: $ 7.04 net ($ 8.65 gross)
(the indicative cost of delivery on Poland's territory)
The indicative delivery cost in EU - 20€ DHL/30€ UPS
More info at manufacturer site
Broken link? Report us.
Kluczowe cechy / Key features :
1. Intel® H5 Socket (LGA 1200), Supports the 10th Gen Intel® Core™ Processors (i3/i5/i7/i9), Pentium® and Celeron® (Comet Lake) Processors
2. Intel Z490 Express Chipset
3. 4 DDR4 UDIMM, 2933 up to 4000(OC)MHz, 128GB Max
4. 4 PCIe3.0 x16 slots(16/NA/16/NA, 8/8/8/8), 1 PCI-E 3.0x1 slot,
5. 4 SATA3.0 ports, 2 M.2(32Gb/s, PCI-E 3.0 x 4) connector (one 2260/2280/22110; one 2260/2280)
6. 1 USB3.2 Gen.2 x2 ports(20Gb/s) Type C + 4 USB3.2 Gen.2 Type A ports+ 4 USB3.2 Gen.1 ports (2 Rear, 2 ports via header) +2 USB 2.0 Ports (via header)
7. I/O Connectors
8. 1 DP 1.2+1 HDMI 2.0a
9. 10 Gbit LAN 1 Gbit LAN Ports, i219V + AQC107
10. Wi-Fi 6 – 1.7 GBit Wireless LAN + Bluetooth 5.0 (C9Z490-PGW only)
11. HD Audio 7.1 channel connector by Realtek ALC1220
12. 5 4-Pins Fan, TPM header, 1 COM Port headers
13. 9.6” x 12 ” ATX
14. 0 ~ 40 Degree °C Operation Temperature.
15. FCC B and EuP ready, WHQL
16. Bios Restore Buttons from USB disk(works with any USB ports)
17. Support 4 way DX12/AMD Cross-fires
Product description
We try to be as accurate as possible, however we do not guarantee that the product descriptions on our site are current or error free.
Please verify them on the manufacturer's website by clicking this link.
| Manufacturer | Supermicro | ||||
|---|---|---|---|---|---|
| SKU | MBD-C9Z490-PG | ||||
| Basic informations | |||||
| Chipset | Z490 Express | ||||
| Format | ATX | ||||
| Size | 12" x 9.6" | ||||
| Expansion slots # | 0 | ||||
| Processor | |||||
| CPU socket | LGA1200 | ||||
| CPU family | Intel Core 10th i9 i7 i5 i3 LGA1200 | ||||
| CPU builtin | No | ||||
| Max. CPU # | 1 | ||||
| SNK shape | Standard | ||||
| System Memory | |||||
| Max. memory size support | 128 GB | ||||
| Memory sockets # | 4 | ||||
| Memory correction support | UN | ||||
| Memory size type support | DIMM | ||||
| Memory type support | DDR4 | ||||
| On-Board Devices | |||||
| SATA support | Yes | ||||
| SATA sockets # | 4 | ||||
| SAS support | No | ||||
| NVMe support | No | ||||
| M.2 support | Yes | ||||
| M.2 sockets # | 2 | ||||
| NIC # | 1 | ||||
| NIC chipset/type |
|
||||
| Hardaware RAID | No | ||||
| IPMI | Yes | ||||
| VGA | Yes | ||||
| Other | |||||
| Supported RSC | N/D | ||||
| Application | High-efficiency, Cost-effective | ||||
| Power consumption | 100 W | ||||
Product description errors? Please let us know.
