H13SAE-MF
Motherboard Supermicro MBD-H13SAE-MF SoC LGA1718 AMD Ryzen 7000 SATA M.2 DDR5
Net: $ 415.80
Gross: $ 511.43
Manufacturer: Supermicro
Part number: H13SAE-MF
Warehouse product ID: 1290101, 1290102
HS: 8473 30 20 00
ECCN: 5A992C
Availability*: PL: NoneNL: 31 pcs. (estimated delivery time from 4 to 10 business days)
* Please remember that delivery times are also influenced by events beyond our and the manufacturer's control, such as random events, armed conflicts or natural disasters.
Delivery cost: $ 7.04 net ($ 8.66 gross)
(the indicative cost of delivery on Poland's territory)
The indicative delivery cost in EU - 20€ DHL/30€ UPS
More info at manufacturer site
Broken link? Report us.
Kluczowe cechy / Key features :
1. AMD EPYC™ 4004 series and Ryzen™ 7000 Series Processors single socket LGA-1718 (socket AM5), up to 170W.
2. Up to 192GB ECC/non-ECC Unbuffered DIMM, DDR5-5200MHz, in 4 DIMM slots.
3. 2 PCIe 5.0 x16 (16/NA or 8/8), support up to 2 GPU cards(mechanical is up to 1 triple-width GPU card or 2 double-width GPU cards) 1 PCIe 4.0 x4
4. 2x 1Gbit LAN port(i210 AT); a dedicated Realtek 1Gbit LAN for IPMI.
5. Micro-ATX form factor
6. 1 USB 3.2 Gen2x2 ports (type C, 20Gb, rear); 5 USB 3.2 Gen2 ports(2 Type C, rear, support DP 1.4 Alt mode)
7. 1 HDMI 2.0 port, 1 DP 1.4a port
Product description
We try to be as accurate as possible, however we do not guarantee that the product descriptions on our site are current or error free.
Please verify them on the manufacturer's website by clicking this link.
| Manufacturer | Supermicro |
|---|---|
| SKU | MBD-H13SAE-MF |
| Basic informations | |
| Chipset | SoC |
| Format | mATX |
| Size | 9.6" x 9.6" |
| Expansion slots # | 3 |
| Processor | |
| CPU socket | LGA1718 |
| CPU family | AMD Ryzen 7000 |
| CPU builtin | No |
| Max. CPU # | 1 |
| SNK shape | Standard |
| System Memory | |
| Max. memory size support | 128 GB |
| Memory sockets # | 4 |
| Memory correction support | NON-ECC |
| Memory size type support | DIMM |
| Memory type support | DDR5 |
| On-Board Devices | |
| SATA support | Yes |
| SATA sockets # | 4 |
| SAS support | No |
| NVMe support | No |
| M.2 support | Yes |
| M.2 sockets # | 2 |
| Hardaware RAID | No |
| IPMI | No |
| VGA | No |
| Other | |
| Supported RSC | N/D |
| Application | High-efficiency, Cost-effective |
| Power consumption | 170 W |
Product description errors? Please let us know.
