H12SSG-ANP6

Motherboard Supermicro MBD-H12SSG-ANP6 SoC SP3 AMD Ryzen 5000 SATA/SAS NVMe M.2 DDR4 IPMI

Supermicro
H12SSG-ANP6
Image above may show a varied configuration or optional parts.

Ask for price

Manufacturer: Supermicro
Part number: H12SSG-ANP6

Availability*: On order (estimated delivery time from 10 to 21 business days)

* Please remember that delivery times are also influenced by events beyond our and the manufacturer's control, such as random events, armed conflicts or natural disasters.

Delivery cost: $ 6.97 net ($ 8.57 gross)
(the indicative cost of delivery on Poland's territory)
The indicative delivery cost in EU - 20€ DHL/30€ UPS

Add to wishlist

More info at manufacturer site
Broken link? Report us.

To avoid steep bank's fee you may pay via SEPA transfer (EURO) or Revolut (Express Elixir) and Wise (Elixir) for payment in USD and EURO.
Add to cart Negotiate the price
Rate product:
No votes.

Kluczowe cechy / Key features :

1. Single AMD Ryzen™ Threadripper™ PRO 5000WX/3000WX Series Processor
2. 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
3. Expansion slots: 3 PCI-E 4.0 x16 Riser Slots, 9 PCI-E 4.0 x8 SlimSAS, 2 PCI-E 4.0 x4 SlimSAS, 1 PCI-E 4.0 x16 AIOM networking slot, M.2 Interface: 2 PCI-E 4.0 x4, M.2 Form Factor: 2242, 2260, 2280, 22110, M.2 Key: M-key
4. 2 NVMe via SlimSAS, 2 M.2
5. Dedicated IPMI 2.0 LAN
6. ASPEED AST2600 BMC graphics
7. 2 USB 3.0 ports (rear)

Product description

We try to be as accurate as possible, however we do not guarantee that the product descriptions on our site are current or error free.
Please verify them on the manufacturer's website by clicking this link.

Manufacturer Supermicro
SKU MBD-H12SSG-ANP6
Basic informations
Chipset SoC
Format Proprietary
Size 9.6" x 14.5"
Expansion slots # 4
Processor
CPU socket SP3
CPU family AMD Ryzen 5000
CPU builtin No
Max. CPU # 1
SNK shape Narrow
System Memory
Max. memory size support 2048 GB
Memory sockets # 8
Memory correction support ER
Memory size type support DIMM
Memory type support DDR4
On-Board Devices
SATA support No
SATA sockets # 0
SAS support Yes
SAS sockets # 2
SAS type SAS2
NVMe support Yes
NVMe sockets # 2
M.2 support Yes
M.2 sockets # 2
NIC # 1
NIC chipset/type
Chipset Type
RTL8211F PHY 1GbE
Hardaware RAID No
IPMI Yes
VGA Yes
Other
Supported RSC N/D
Application High-efficiency, Cost-effective
Power consumption 100 W
