X9SCAA

Motherboard Supermicro MBD-X9SCAA nm10 FCBGA559 Intel Atom N2800 FCBGA559 SATA DDR3

Supermicro
Product unavailable (EOL) or limited sale (shortage). Please contact.
You can check our refurbished list on our blog https://www.serverparts.pl/en/blog?q=refurbished
X9SCAA
Image above may show a varied configuration or optional parts.

Net: $ 171.20

Gross: $ 210.58

Availability: EOL

Manufacturer: Supermicro
Part number: X9SCAA
Warehouse product ID: 3870, 4279
Size of the package (LxWxH): 47cm x 38cm x 9cm
UPC/EAN: 672042128433

Availability*: On order (estimated delivery time from 10 to 21 business days)

* Please remember that delivery times are also influenced by events beyond our and the manufacturer's control, such as random events, armed conflicts or natural disasters.

Delivery cost: $ 7.04 net ($ 8.67 gross)
(the indicative cost of delivery on Poland's territory)
The indicative delivery cost in EU - 20€ DHL/30€ UPS

Kluczowe cechy / Key features :

1. Intel® Atom™ N2800 (6.5W)
2. Intel® NM10 Express Chipset
3. Up to 4GB 1066MHz DDR3 Non-ECC, SO-DIMM in 2 sockets
4. 1x Mini-PCIe with mSATA
5. HDMI, Display port, LVDS and VGA
6. Dual Intel 82574L GbE LAN ports
7. 2x USB 3.0 and 6x USB 2.0 ports
8. 4x COM ports
9. DOM power connector
10. 12V DC or ATX power source
11. Operating Temperature: 0°C - 60°C
12. 4-pin 12V DC power input or 24-pin ATX power input

Product description

We try to be as accurate as possible, however we do not guarantee that the product descriptions on our site are current or error free.
Please verify them on the manufacturer's website by clicking this link.

Manufacturer Supermicro
SKU MBD-X9SCAA
Basic informations
Chipset nm10
Format Mini-ITX
Size 6.75" x 6.75"
Expansion slots # 1
Processor
CPU socket FCBGA559
CPU family Intel Atom N2800 FCBGA559
CPU builtin Yes
Max. CPU # 1
SNK shape Square
System Memory
Max. memory size support 4 GB
Memory sockets # 2
Memory correction support NON-ECC
Memory size type support SODIMM
Memory type support DDR3
On-Board Devices
SATA support Yes
SATA sockets # 2
SAS support No
NVMe support No
M.2 support No
NIC # 2
NIC chipset/type
Chipset Type
82574L 1GbE
82574L 1GbE
Hardaware RAID No
IPMI No
VGA Yes
Other
Supported RSC CSE-RR32-1U
Application Cost-effective
Power consumption 50 W
