X9SCV-Q
Motherboard Supermicro MBD-X9SCV-Q QM67 rPGA 988B Intel Core 2nd/3rd i7 i5 i3 Sandy Bridge LGA1155 SATA DDR3
You can check our refurbished list on our blog https://www.serverparts.pl/en/blog?q=refurbished
Net: 782,76 zł
Gross: 962,79 zł
Availability: EOL
Manufacturer: Supermicro
Part number: X9SCV-Q
Warehouse product ID: 385, 386
Size of the package (LxWxH): 47cm x 38cm x 9cm
UPC/EAN: 672042090990
Availability*: PL: NoneNL: 1 pcs. (estimated delivery time from 4 to 10 business days)
* Please remember that delivery times are also influenced by events beyond our and the manufacturer's control, such as random events, armed conflicts or natural disasters.
Delivery cost: 30,00 zł net (36,90 zł gross)
(the indicative cost of delivery on Poland's territory)
The indicative delivery cost in EU - 20€ DHL/30€ UPS
Kluczowe cechy / Key features :
1. Intel® 2nd Generation Core i7/i5/i3, Celeron Processor B800 series, supported; socket G2 (rPGA 988B)
2. Intel® QM67 Chipset
3. Up to 16GB DDR3 1066/1333MHz, Non-ECC SODIMMs
4. 1x PCI-E 2.0 x16 slot
5. 4x SATA2 3Gb/s w/ RAID 0, 1, 5, 10; 2x SATA3 6Gb/s w/ RAID 0, 1
6. 2x HDMI ports, VGA D-Sub connector, 2x COM ports (1 rear + 1 header)
7. Intel® 82579LM and 82574L, Dual Gigabit Ethernet LAN ports
8. 11x USB 2.0 ports (6 rear + 4 via header + 1 Type-A)
9. HD Audio Header, front panel audio Header; integrated graphics
10. DOM Power connector
11. vPro 7.0 AMT7.0, TPM 1.2 onboard
Product description
We try to be as accurate as possible, however we do not guarantee that the product descriptions on our site are current or error free.
Please verify them on the manufacturer's website by clicking this link.
| Manufacturer | Supermicro | ||||||
|---|---|---|---|---|---|---|---|
| SKU | MBD-X9SCV-Q | ||||||
| Basic informations | |||||||
| Chipset | QM67 | ||||||
| Format | Mini-ITX | ||||||
| Size | 6.75" x 6.75" | ||||||
| Expansion slots # | 1 | ||||||
| Processor | |||||||
| CPU socket | rPGA 988B | ||||||
| CPU family | Intel Core 2nd/3rd i7 i5 i3 Sandy Bridge LGA1155 | ||||||
| CPU builtin | No | ||||||
| Max. CPU # | 1 | ||||||
| SNK shape | Standard | ||||||
| System Memory | |||||||
| Max. memory size support | 16 GB | ||||||
| Memory sockets # | 2 | ||||||
| Memory correction support | EC | ||||||
| Memory size type support | SODIMM | ||||||
| Memory type support | DDR3 | ||||||
| On-Board Devices | |||||||
| SATA support | Yes | ||||||
| SATA sockets # | 6 | ||||||
| SAS support | No | ||||||
| NVMe support | No | ||||||
| M.2 support | No | ||||||
| NIC # | 2 | ||||||
| NIC chipset/type |
|
||||||
| Hardaware RAID | No | ||||||
| IPMI | No | ||||||
| VGA | Yes | ||||||
| Other | |||||||
| Supported RSC | N/D | ||||||
| Application | High-efficiency, Cost-effective | ||||||
| Power consumption | 45 W | ||||||
